The powder particles are screened and graded by vibration to achieve the purpose of fine sorting.
Price:$800.00-$4,500.00/Set
Consult now and enjoy a 10% discount
Diameter: 400mm(15"), 600mm(24"), 800mm(31"), 1000mm(39"), 1200mm(47"), 1500mm(59"), 1800mm(70"), 2000mm(78")
Mesh size: 2-500 mesh
Capacity: 100-3300kg/h
Screen frame: 1-5 layers (3 layers is best)
Motor power: 0.25Kw to 2.2Kw or customized
Application: Powder sifter machines are widely used in chemical, food, pharmaceutical and other fields to screen and grade powder and granular materials and remove impurities.
Commitment: Free Shipping/5 Days Delivery/30-Day Returns/Support Customization
Powder sifter machine is a kind of equipment used for screening and grading powder and granular materials. It mainly includes vibrating screen, centrifugal screen, cyclone screen, high-efficiency screen and other types. Powder sifter machine is widely used in chemical, food, pharmaceutical and other industries. It can remove impurities, control particle size, improve product quality and meet different production needs. Its functions include separating particles, improving production efficiency and reducing energy consumption. It is one of the important screening equipment in the industrial production process.
In the chemical industry, the main application of the powder sieve machine is the filtration and sieving of powder particles, sludge, liquid. In the food industry, it is mainly used in the screening of flour, starch, tofu and other food raw materials, as well as the filtration and separation of sugar, salt, chili powder, etc. In the pharmaceutical industry, powder sieving machines are mainly used in the crushing and sieving of pharmaceuticals, as well as the filtration and separation of solid pharmaceutical particles. In the metallurgical and mining industry, the main application of the powder sieve machine is the separation and filtration of ore and metal particles.
The working principle of the powder sifter machine is based on vibration and screen separation technology. Its main components include vibration motor, screen, spring and screen frame.
Vibration motor: After starting, the vibration motor generates high-frequency vibration, which makes the screen frame and screen vibrate.
Material supply: The powder to be screened enters the screen surface evenly through the feed port.
Screening process: Due to the vibration, the powder moves quickly on the screen. Fine particles fall into the lower layer of coarse materials through the screen aperture and are retained on the screen, and finally discharged from different outlets.
Grading and discharge: Themachine can be equipped with multiple layers of screens to achieve multi-stage separation, and materials of different particle sizes are discharged from different outlets.
Efficient screening
It can quickly and effectively screen and grade powder particles to improve production efficiency.
Accurate sorting
By setting sieve holes of different sizes, the size of particles can be accurately controlled to ensure product quality.
Impurity removal
It can effectively remove impurities and foreign matter to improve the purity and quality of products.
Diverse screening
It is suitable for materials of different particle sizes and shapes, and can be flexibly applied to various industrial production needs.
Energy saving and environmental protection
The use of vibration or rotation can reduce energy consumption and meet energy saving and environmental protection requirements.
Easy operation
The equipment has a simple structure, is easy to operate and maintain, and reduces the labor cost and maintenance cost in the production process.
| Model | Diameter (mm) |
Feeding Size (mm) |
Frequency (RPM) |
Layers | Power (kw) |
| DH-400 | 400 | <10 | <1500 | 1-5 | 0.18 |
| DH-600 | 600 | 0.25 | |||
| DH-800 | 800 | 0.55 | |||
| DH-1000 | 1000 | 0.75 | |||
| DH-1200 | 1200 | 1.1 | |||
| DH-1500 | 1500 | 1.5 | |||
| DH-1800 | 1800 | 2.2 |
A chemical company in a certain place focuses on the production of chemical raw materials. The company uses a powder sifter machine to screen and grade powder raw materials to ensure product quality and production efficiency. Through the precise screening of the powder screening machine, impurities can be removed and particle size can be controlled. This fine screening not only improves the purity and uniformity of the product, but also reduces waste and loss in the production process, and improves production efficiency and profits.
