Stainless steel vibrating sieve for sieving traditional Chinese medicine powder: safety seal, sieving below 500 mesh

Traditional Chinese medicine powder is the powder formed by grinding all kinds of traditional Chinese medicine. After grinding the traditional Chinese medicine into powder according to the standard, it is necessary to perform "sieve analysis" on the ground traditional Chinese medicine powder to separate the coarse powder and fine powder, and divide the crushed powder into different grades. Or sieve out large particles that do not meet the requirements to facilitate the preparation of various dosage forms; in addition, the medicinal powder can be mixed to ensure the uniformity of the medicine in the preparation.

Stainless steel vibrating sieve is mainly used for non-sticky herbal medicines, chemical medicines, and drug powders that are toxic, irritating, easily weathered or deliquescence, such as licorice, angelica, ganoderma lucidum, salvia, spirulina, pearl powder, etc.

The vibrating sieves used in the sieving of traditional Chinese medicine powder are all stainless steel vibrating sieves made of 304 or 316L (316L pharmaceutical grade stainless steel is recommended for medicinal material sieving), which can meet the national GMP standard and ensure safety, health, non-toxicity and harmlessness.

Stainless steel vibrating sieve can effectively sieve traditional Chinese medicine powder below 500 mesh:

The sieving standard mesh of medicinal powder is from 10 mesh to 200 mesh. Generally, the sieving mesh of traditional Chinese medicine powder can be selected from 80 to 100 mesh. Some traditional Chinese medicine powder can be selected as fine as 200 mesh. effect.

The mesh number of the stainless steel vibrating sieve can be as fine as 500 meshes, which can meet the sieving requirements of most traditional Chinese medicine powders.

The stainless steel vibrating sieve has 1-5 layers of mesh, which can divide the traditional Chinese medicine powder into 2-6 specifications:

According to different uses, traditional Chinese medicine powder should have different mesh numbers:

Oral administration: 80-100 mesh, convenient for torment

Pills (water pills, honey pills, etc.): 150-200 mesh

Granules, ointments, capsules, etc.: 300 mesh or more for easy consumption

The stainless steel vibrating sieve can be added to a maximum of 5 layers, and each layer can be placed with different meshes, so that one machine can complete the sieving requirements of various uses of traditional Chinese medicine powder.

Stainless steel vibrating sieve pharmaceutical grade silicone sealing ring:

In addition to the stainless steel vibrating sieve when processing traditional Chinese medicine powder, the body is made of pharmaceutical grade stainless steel, and its seals and accessories such as net-clearing pinballs also use pharmaceutical grade silicone material, which has excellent sealing performance and ensures no dead ends. Safe and hygienic sieving.

Add stainless steel sieve cover, the sieve cover is equipped with a perspective mirror observation window:

Because of its light and thin texture, traditional Chinese medicine powder is easily scattered during the sieving process, resulting in waste of medicinal powder. Some traditional Chinese medicine powders are pungent or slightly toxic, which will also affect the staff. The stainless steel vibrating sieve for traditional Chinese medicine powder can be equipped with a sieve cover, so The feeding port is directly connected to the crushing equipment, and the observation window of the perspective mirror on the sieve cover can know the sieving situation in the frame at any time during the sieving process, and the sealing design also reduces the external pollution of the traditional Chinese medicine powder.
