Small Stainless Steel Screw Conveyor-DAHAN Vibration Machinery

Introduction of Small Stainless Steel Screw Conveyor

The small stainless steel screw conveyor is made of SUS304 or 316L stainless steel. It is manufactured for specific applications where ordinary carbon steel small screw conveyors cannot meet the application requirements. Common applications include food, chemicals, pharmaceuticals, and any other that requires its hygiene, Corrosive or extreme temperature applications.

Small Stainless Steel Screw Conveyor

The screw diameter of small stainless steel screw conveyor is 100mm-159mm, the length (centre distance between import and export) is generally 100mm-2000mm, and the conveying capacity is 0.01kg/h-1000kg/h. It is specially designed for small feeding speed and laboratory applications. Installation Below the silo or the main screw feeder as a feeding device.

Application of Small Stainless Steel Screw Conveyor

Small stainless steel screw conveyor is specially used in food, medicine, chemical industry for conveying and metering small amount of materials such as powder, granules and pellets, corrosion resistant and easy to clean, the following are some common uses of Small Stainless Steel Screw Conveyor:

Food industry: used to transport ingredients such as spices, condiments and food additives.

Pharmaceutical industry: For transporting active pharmaceutical ingredients (API) and excipients.

Chemical industry: used to transport chemicals and additives.

Agricultural industry: it is used to transport various agricultural products such as chemical fertilizers, pesticides, and animal feed.

Plastic industry: used to transport plastic additives, colorants and fillers.

Benefits of Small Stainless Steel Screw Conveyor

Preservative

The stainless steel construction of the screw and housing make the conveyor highly corrosion resistant, which is important in industries where materials may be chemically reactive or corrosive.

Durability

Stainless steel is a strong and durable material, which means the conveyor can withstand heavy use and resist wear and tear over time.

Hygiene

Stainless steel is easy to clean and sanitize, making it ideal for food, pharmaceutical and other industries where cleanliness is critical.

Small footprint

The length is 100-2000mm, which can reliably and accurately feed various dry powder and granular materials in a very small footprint.

Small delivery volume

The production capacity varies from 0.5kg/hour to 1000kg/hour, suitable for any occasion where precise small quantities are required.

Customizable

Small Stainless Steel Screw Conveyors are highly customizable with a choice of different screw designs, housing shapes and sizes, inlet and outlet configurations, and control systems to meet the specific needs of the application.

Technical Parameters of Small Stainless Steel Screw Conveyor

Model	Spiral diameter (mm)	Pitch (mm)	Speed (r/min)	Delivery capacity (m3/h)	Motor power (kw)
100	114	3	100	1	0.15-0.45
114	114	5-10	140	3	1.6
159	159	10	120	10	1.5
160	160	35	120	8	2.8

Customer Case

Here are some examples of customer cases using small stainless steel screw conveyors:

1\Food industry

A company that produces flavored coffee creamers needed a way to transport and meter small quantities of powdered ingredients such as sugar, flavorings, and creamer. They installed small stainless steel screw conveyors with custom screw designs to ensure accurate metering of ingredients.

2\Pharmaceutical industry

Pharmaceutical manufacturers need to transport and meter small quantities of active pharmaceutical ingredients (APIs) and excipients for their tablet manufacturing process. They installed small stainless steel screw conveyors with custom hopper and inlet designs to ensure reliable, efficient material movement.

3\ Chemical Industry

Chemical manufacturers need to transport and meter small quantities of various chemicals for their production processes. They installed small stainless steel screw conveyors with custom housing and screw designs to ensure efficient and accurate material transfer.

4\Agricultural industry

A feed manufacturer needs to transport and meter small quantities of animal feed ingredients such as vitamins, minerals and grains. They installed a small stainless steel screw conveyor with a custom feeder and outlet design to ensure consistent and accurate metering of ingredients.

5\Water treatment industry

Water treatment plants need to transport and meter small amounts of various chemicals in the treatment process. They installed a small stainless steel screw conveyor with a custom housing and screw design to ensure efficient and accurate transport of the chemicals.
