How much dose a U screw conveyor cost?

The cost of a U screw conveyor can vary depending on several factors such as the size and capacity of the conveyor, the materials used to construct it, the manufacturer, and the location of the buyer. However, as a rough estimate, a basic U screw conveyor with a standard length of 10-12 feet and a diameter of 6-8 inches may cost anywhere from $2,000 to $5,000 USD.

How much dose a U screw conveyor cost

Specification		Main technical performance	Drive device	Drive device			Price (USD)
Diameter	Length(m)	Yield( t/h)	Rotating speed(min)	Reducer		Electric motor
Diameter	Length(m)	Yield( t/h)	Rotating speed(min)	Model	Speed ratio	Power(kw)
U 200	-10	9	60	ZQ250	23.34	1.1	$540
U 200	-20	9	60	ZQ250	23.34	1.5	$600
U 250	-10	15.6	60	ZQ250	23.34	2.2	$750
U 250	-20	15.6	60	ZQ250	23.34	3	$820
U 300	-10	21.2	60	ZQ350	23.34	3	$940
U 300	-20	21.2	60	ZQ350	23.34	4	$1,200
U 400	-10	51	60	ZQ400	23.34	5.5	$1,500
U 400	-20	51	60	ZQ500	23.34	11	$2,600
U 500	-10	87.5	60	ZQ400	23.34	7.5	$3,200
U 500	-20	87.5	60	ZQ650	23.34	18.5	$4,500
U 600	-10	134.2	45	ZQ750	23.34	22	$5,000
U 600	-10	134.2	45	ZQ850	23.34	55	$5,400

1. Model size -- the bigger, the more expensive

Different types of screw conveyors have different prices per meter, for example, the price difference between U200 screw conveyor and U250 screw conveyor is US$150 per meter.

2.the material -- the price of stainless steel is 1 times more expensive

Material has carbon steel, stainless steel, stainless steel material price is about 1 times more expensive, stainless steel is mainly used for the transport environment requirements of the industry, high cleanliness, will not pollute materials, long use time, the cost is relatively high.

3. Bearing -- sliding bearing is 1 times more expensive than rolling

Compared with rolling bearings, sliding bearings are equipped with dustproof sealing device, and the acceptable material temperature is above 100 degrees, the overall heat resistance is much better.

4. Motors -- explosion-proof, waterproof and heat-resistant motors are 1-2 times more expensive

The explosion-proof, waterproof and heat-resistant motors are more suitable for the harsh production environment and can ensure the safe operation of the production line, so the price will be 1-2 times more expensive.

5. manufacturer -- big man price more reasonable

You get what you pay for. We don't ask for the cheapest things, but we definitely want to buy the most cost-effective products. Dahan production of u-type screw conveyor not only quality, but also the price is very competitive!
