Design Options for Stainless Steel Inclined Screw Conveyor

In order to adapt to changing application scenarios, Stainless Steel Inclined Screw Conveyor can be designed in many different forms. This article uses some design forms as examples. If you have other design needs, please contact us directly.

Screw form: The screw shaft of the Stainless Steel Inclined Screw Conveyor mainly has two forms: shafted and shaftless. The inclination angle is below 30°, and the screw with shaft or shaftless can be selected arbitrarily. If the conveying angle exceeds 30°, choose shafted Screw conveyor.

Fixed movable wheels: If the conveying site of the Stainless Steel Inclined Screw Conveyor needs to be changed frequently, such as for docks; bulk grain, sand and gravel; loading, etc., the design of movable wheels can be added, which can be adjusted according to the change of the actual conveying needs. Mobile, and during the conveying process, the movable wheels can be fixed to improve the safety of conveying.

Self-contained large silo: The basic feed silo can be specially designed and modified into a large silo, which can control the feed flow and provide certain material storage functions.

Liftable design: It is used for the situation that the actual conveying angle is many or the conveying angle is not fixed, and the height of the conveyor can be adjusted, but it is only suitable for the design and use of small and medium-sized Stainless Steel Inclined Screw Conveyor.

Motor: Single-phase or three-phase motors can be selected according to the power supply of the factory. Or choose sealed and explosion-proof motors according to the characteristics of the conveyed materials.
